Experiments with Digital Electronics

The field of digital electronics is central to modern technology.

This book presents fundamental circuits using gates, flip-flops and counters from the CMOS 4000 Series.

Each of the 50 experiments has a circuit diagram as well as a detailed illustration of the circuits construction on solderless breadboard.

Learning these fundamentals is best done using practical experiments.

Building these digital circuits will improve your knowledge and will be fun to boot.

Many of the circuits presented here have practical real-life applications.

With a good overview of the field, you will be well-equipped to find simple and cost-effective solutions for any application.

The book is targeted essentially at students, trainees and anyone with an interest in and requiring an introduction to digital control electronics.

Moreover, the knowledge gleaned here is the foundation for further projects in the field of microcontrollers and programming.
